Proceedings of the 41st International Conference on Advanced Ceramics and Composites, Volume 38, Issue 2 ebook

Proceedings of the 41st International Conference on Advanced Ceramics and Composites

Ceramic Engineering and Science Proceedings, Volume 38, Issue 2, 2017

A Collection of Papers Presented at the 41st International Conference on Advanced Ceramics and Composites January 22–27, 2017, Daytona Beach, Florida

This edition first published 2018© 2018 The American Ceramic Society

All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, except as permitted by law. Advice on how to obtain permission to reuse material from this title is available at http://www.wiley.com/go/permissions.

The rights of Jonathan Salem, Jerry C. LaSalvia, Roger Narayan, Dongming Zhu, Surojit Gupta, and Jingyang Wang to be identified as the authors of the editorial material in this work have been asserted in accordance with law.

Registered OfficeJohn Wiley & Sons, Inc., 111 River Street, Hoboken, NJ 07030, USA

Editorial Office111 River Street, Hoboken, NJ 07030, USAFor details of our global editorial offices, customer services, and more information about Wiley products visit us at www.wiley.com.

Wiley also publishes its books in a variety of electronic formats and by print-on-demand. Some content that appears in standard print versions of this book may not be available in other formats.

Limit of Liability/Disclaimer of WarrantyWhile the publisher and authors have used their best efforts in preparing this work, they make no representations or warranties with respect to the accuracy or completeness of the contents of this work and specifically disclaim all warranties, including without limitation any implied warranties of merchantability or fitness for a particular purpose. No warranty may be created or extended by sales representatives, written sales materials or promotional statements for this work. The fact that an organization, website, or product is referred to in this work as a citation and/or potential source of further information does not mean that the publisher and authors endorse the information or services the organization, website, or product may provide or recommendations it may make. This work is sold with the understanding that the publisher is not engaged in rendering professional services. The advice and strategies contained herein may not be suitable for your situation. You should consult with a specialist where appropriate. Further, readers should be aware that websites listed in this work may have changed or disappeared between when this work was written and when it is read. Neither the publisher nor authors shall be liable for any loss of profit or any other commercial damages, including but not limited to special, incidental, consequential, or other damages.

Library of Congress Cataloging-in-Publication Data is availableISBN: 9781119474548ISSN: 0196-6219

Cover design by Wiley

Contents

Introduction

MECHANICAL BEHAVIOR AND PERFORMANCE OF CERAMICS AND COMPOSITES

The Effects Of Diamond Grit Characteristics on the Microstructure and Abrasion Resistance of PCDs Sintered by HPHT

Crush Strength Analysis of Hollow Glass Microspheres

Use of Electrical Resistance and Acoustic Emission during Fatigue of Woven SiC/SiC Composites under Different Conditions

Mechanical Behavior of Wound All-Oxide CMCs

Oxidative Exposure of Ceramic Matrix Composites: Post Flex and Acoustic Emission Analysis

Dry Sliding Wear and Friction Behavior of Hybrid ZA-27 Alloy Composites Reinforced with Silicon Carbide and Stone Dust Particulates

High Hardness and Toughness Nano-CBN-WC-W(RE) Composite

Fracture Toughness of Glasses as Measured by the SCF and SEPB Methods

Use of Electrical Resistance as a Non-Destructive Evaluation Tool in Health Monitoring and Damage Evaluation of Ceramic Matrix Composites.

Potentials of Niobium Carbide (NbC) as Cutting Tools and for Wear Protection

ADVANCED CERAMIC COATINGS

Effect of Microstructural Characteristics on Thermal and Electrical Properties of Thermally Sprayed Ceramic Coatings

Magnetic Studies of Copper Incorporated Iron Nitride Thin Films

EBC Slurry Infiltrated Matrix/Coatings for Woven SiC/SiC Composites

ARMOR CERAMICS

The Role of Inertia in Armor Ceramics

Molecular-Dynamic Modeling of Propagation of Shock Wave in Porous Ceramic Materials

Evaluation of Temperature Jump at the Front of Comminution and Compaction of the Ceramic Target Material at High-Velocity Impact

Computer Modeling of Projectile Penetration into Hybrid Armor Panel with Regular Packing of Ceramic Discrete Elements

Improved De-Gassing and De-Agglomeration of ISOBAM Gel Casting System for Alumina using Micro-Computed Tomography

Synthesis, Sintering, Structure and Properties of ALB12C2 - Based Materials

Analysis of the Interaction of Projectiles with Ceramic Targets by Means of Flash X-Ray Cinematography and Optical Methods

NEXT GENERATION BIOCERAMICS

Development of Strong and Tough Bioactive Glass Composites for Structural Bone Repair

Three-Dimensional Printing of Si3N4 Bioceramics by Robocasting

Challenges in Development of Easy-To-Use Torsion Test Method for Bioceramics - Toward ISO Standard Proposal

Eula

List of Tables

Chapter 2

Table 1

Table 2

Table 3

Chapter 3

Table 1

Table 2

Chapter 4

Table 1

Table 2

Table 3

Table 4

Table 5

Table 6

Chapter 5

Table 1

Chapter 6

Table 1

Table 2

Table 3

Table 4

Table 5

Table 6

Chapter 7

Table 1

Table 2

Chapter 8

Table 1

Table 2

Chapter 10

Table 1

Table 2

Chapter 11

Table 1

Chapter 12

Table 1

Table 2

Table 3

Table 4

Table 5

Chapter 13

Table 1

Table 2

Chapter 16

Table 1

Table 2

Table 3

Table 4

Chapter 18

Table 1

Table 2

Table 3

Table 4

Chapter 19

Table 1

Table 2

Table 3

Chapter 20

Table 1

Table 2

Chapter 21

Table 1

Chapter 22

Table 1

Chapter 23

Table 1

Table 2

Table 3

Table 4

List of Illustrations

Chapter 1

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Figure 7

Figure 8

Chapter 2

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Figure 7

Figure 8

Figure 9

Figure 10

Figure 11

Figure 12

Chapter 3

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Figure 7

Figure 8

Figure 9

Figure 10

Figure 11

Figure 12

Figure 13

Chapter 4

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Chapter 5

Figure 1

Figure 2

Figure 3

Figure 4

Chapter 6

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Chapter 7

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Chapter 8

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 7

Figure 8

Figure 9

Figure 10

Figure 11

Figure 12

Chapter 9

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Chapter 10

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Figure 7

Figure 8

Figure 9

Figure 10

Figure 12

Figure 13

Figure 14

Chapter 11

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Chapter 12

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Figure 7

Chapter 13

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Figure 7

Figure 8

Figure 9

Chapter 14

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Figure 7

Figure 8

Figure 9

Chapter 15

Figure 1

Figure 2

Figure 3

Chapter 16

Figure 1

Figure 2

Figure 3

Chapter 17

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Chapter 18

Figure 1

Figure 2

Chapter 19

Figure 1

Figure 2

Figure 3

Chapter 20

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Figure 7

Figure 8

Figure 9

Figure 10

Figure 11

Figure 12

Figure 13

Figure 14

Figure 15

Figure 16

Figure 17

Figure 18

Figure 19

Figure 20

Figure 21

Chapter 21

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Chapter 22

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Chapter 23

Figure 1

Figure 2

Figure 3

Figure 4

Figure 5

Figure 6

Figure 7

Figure 8

Figure 9

Figure 10

Figure 11

Figure 12

Figure 13

Figure 14

Figure 15

Guide

Cover

Table of Contents

Chapter 1

Pages

3

4

5

6

7

8

9

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

65

66

67

68

69

70

71

72

73

75

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

99

100

101

102

103

104

105

106

107

108

109

110

111

115

116

117

118

119

120

121

122

123

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

149

150

151

152

153

154

155

156

157

158

159

160

161

162

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

223

224

225

226

227

228

229

230

231

232

233

235

236

237

238

239

240

241

242

243

244

245

246

247

248

249

250

251

252

253

255

256

257

258

259

260

ix

x

xi

iv

C1

iii

1

113

147

221

e1

Introduction

This Ceramic Engineering and Science Proceedings (CESP) issue consists of 23 papers that were submitted and approved from select symposia held during the

41st International Conference on Advanced Ceramics and Composites (ICACC), held January 22–27, 2017 in Daytona Beach, Florida. ICACC is the most promi- nent international meeting in the area of advanced structural, functional, and nanoscopic ceramics, composites, and other emerging ceramic materials and technologies. This prestigious conference has been organized by the Engineering Ceramics Division (ECD) of The American Ceramic Society (ACerS) since 1977.

The 41st ICACC hosted more than 1,000 attendees from 41 countries that gave over 850 presentations. The topics ranged from ceramic nanomaterials to struc- tural reliability of ceramic components, which demonstrated the linkage between materials science developments at the atomic level and macro level structural ap- plications. Papers addressed material, model, and component development and investigated the interrelations between the processing, properties, and microstruc- ture of ceramic materials.

The 2017 conference was organized into the following 15 symposia and 3 Fo- cused Sessions and two Special Sessions:

Symposium 1

Mechanical Behavior and Performance of Ceramics and Composites

Symposium 2

Advanced Ceramic Coatings for Structural, Environmental, and Functional Applications

Symposium 3

14th International Symposium on Solid Oxide Fuel Cells (SOFC): Materials, Science, and Technology

Symposium 4

Armor Ceramics: Challenges and New Developments

Symposium 5

Next Generation Bioceramics and Biocomposites

Symposium 6

Advanced Materials and Technologies for Direct Thermal Energy Conversion and Rechargeable Energy Storage

Symposium 7

11th International Symposium on Functional Nanosmaterials and Thin Films for Sustainable Energy Harvesting, Environmental and Health Applications

Symposium 8

11th International Symposium on Advanced Processing & Manufacturing Technologies for Structural & Multifunctional Materials and Systems

Symposium 9

Porous Ceramics: Novel Developments and Applications

Symposium 10

Virtual Materials (Computational) Design and Ceramic Genome

Symposium 11

Advanced Materials and Innovative Processing ideas for the Production Root Technology

Symposium 12

Materials for Extreme Environments: Ultrahigh Temperature Ceramics (UHTCs) and Nano-laminated Ternary Carbides and Nitrides (MAX Phases)

Symposium 13

Advanced Materials for Sustainable Nuclear Fission and Fusion Energy

Symposium 14

Crystalline Materials for Electrical, Optical and Medical Applications

Symposium 15

Additive Manufacturing and 3D Printing Technologies

Focused Session 1

Geopolymers, Chemically Bonded Ceramics, Eco-friendly and Sustainable Materials

Focused Session 2

Advanced Ceramic Materials and Processing for Photonics and Energy

Focused Session 3Special SymposiumSpecial Symposium

Carbon Nanostructures and 2D Materials and Composites3rd Pacific Rim Engineering Ceramics Summit6th Global Young Investigators Forum (GYIF)

The proceedings papers from this meeting are published in the below two is- sues of the 2017 Ceramic Engineering and Science Proceedings (CESP):

CESP Volume 38, Issue 2

(includes 23 papers from Symposia 1, 2, 4, 5, and GYIF)

CESP Volume 38, Issue 3 (includes 24 papers from Symposia 3, 8, 11, 12, 13, 14, 15 and FS1)

The organization of the Daytona Beach meeting and the publication of these proceedings were possible thanks to the professional staff of ACerS and the tire- less dedication of many ECD members. We would especially like to express our sincere thanks to the symposia organizers, session chairs, presenters and confer-ence attendees, for their efforts and enthusiastic participation in the vibrant and cutting-edge conference.

ACerS and the ECD invite you to attend the 42nd International Conference on Advanced Ceramics and Composites (http://www.ceramics.org/icacc2018) Janu- ary 21-26, 2018 in Daytona Beach, Florida.

To purchase additional CESP issues as well as other ceramic publications, vis- it the ACerS-Wiley Publications home page at www.wiley.com/go/ceramics.

SUROJIT GUPTA, University of North Dakota, USA

JINGYANG WANG, Institute of Metal Research, Chinese Academy of Sciences, China

Volume Editors

August 2017 ICACC

Mechanical Behavior and Performance of Ceramics and Composites

THE EFFECTS OF DIAMOND GRIT CHARACTERISTICS ON THE MICROSTRUCTURE AND ABRASION RESISTANCE OF PCDs SINTERED BY HPHT

Lifen Deng, Roger Nilen and Serdar Ozbayraktar

Global innovation centreElement Six Ltd., Harwell, Oxfordshire, UK

ABSTRACT

Polycrystalline diamond (PCD) compacts used on oil and gas drilling bits were sintered under high-pressure and high-temperature (HPHT) conditions. In this study, the microstructure of polycrystalline diamond composite portion of the compacts is analysed by using scanning electron microscopy (SEM) and image analysis methods. In addition, laboratory rock cutting tests were conducted as a direct measure of abrasion resistance of PDCs produced using different types of diamond powder. Microstructure and abrasion resistance relationships with the grain size, the nitrogen content and the surface quality of diamond grits are discussed. It is found that the PCDs’ abrasion resistance generally decreases with the increasing mean diamond grain size of a sintered PDC. Although the diamond grits with lower nitrogen levels show a higher compression fracture strength, it is not necessarily beneficial for the abrasion resistance of PCDs. It was observed that Type C diamond grits with a rougher surface tends to lead an increasing abrasion resistance of PCD in laboratory rock cutting tests.

INTRODUCTION

Polycrystalline diamonds (PCDs) sintered by HPHT method have been widely used in oil and gas industry as the cutting element on the drilling bit since 1980’s and polycrystalline diamond compact drill bits have accounted for over 60% of drilled footage in 2004[1]. Due to the PCD's super abrasion resistance and reasonably good fracture toughness resistance compared to traditional cutting element materials such as tungsten carbide and hardened steel, PCD compacts have significantly increased the drilling footage and reduced the cost in oil and gas industry [2]. As conventional oil fields are becoming increasingly elusive and continuously reducing the drilling cost is always in demand, the drive for further enhanced abrasion resistance of PCD cutters but not sacrificing too much the fracture toughness is stronger than ever. In the present study, the relationship between the abrasion resistance of PCD cutters and the grain size was discussed. At the same time, 3 different types of Grade 30 (G30, the mean grain size = 30 ͮm) and Grade 22 (G22, the mean grain size = 22 ͮm) diamond grits were used to sinter PCD cutters. Type A diamond powders have a higher nitrogen content than Type B and Type C powders. The surface of Type C diamond grits are rougher than Type B. All PCD cutters were sintered under the same conditions. How the abrasion resistance of PCDs is affected by the nitrogen content and the surface quality of diamond grits was investigated.

EXPERIMENTAL

The nitrogen content of diamond grits were measured by a LECO Nitrogen Analyzer. Each sample was measured 4 times and the average value calculated. In order to investigate the compaction response of diamond grits at high pressure, a cold compaction test was conducted on the three types of G22 and G30 diamond powders. The diamond powders were put into a metal cup and topped with a carbide substrate for the cold compaction at 7 GPa and 8 GPa at room temperature. The particle distribution of diamond grits were measured by Malvern Particle Master Analyzer before and after the cold compaction.

The PCD cutters were sintered under conditions of 1400 to 1600 °C and 5 to 8 GPa [3,4]. Figure 1 shows the schematic design of the pre-sintered unit and the microstructure of PCDs and the tungsten carbide after sintering. During the sintering of PCD, the cobalt in substrate becomes melted and infiltrated into the bed of diamond grits, assisting the sintering of diamonds.

Figure 1 The schematic picture showing the sintering of PCDs.

After sintering, all PCD cutters in the present study were processed to the same dimensions of Ø16mm × 12 mm. The abrasion resistance of PCD was measured through rock cutting tests conducted on vertical turret lathe. After the test, the wear scar were measured under an optical light microscopy. The larger the wear scar area of PDC, the lower the wear resistance. For each sample, 4 rock cutting tests were carried out on two locations of 2 PCD cutters, generateing a total 4 data points.

All PCDs were lapped and polished to 1ͮm before the microstructure observation under SEM. With the intention of quantify the microstructure of PCDs, 20 photos were taken on each sample and processed by the commercially available image analysis software package. The percentage of diamond area is one of the image analysis results of PCDs’ microstructure and used to present the sintering status of PCDs. Given the same powder feed, the higher the percentage of diamond area, the more PCD sintered.

RESULTS AND DISCUSSION

Mean grain size of diamond grits

A series of diamond powders with different average grain sizes were prepare and sintered into PCD cutters at 7 GPa. All PCDs were sintered under the same conditions. The SEM observations confirmed that the microstructures of all PCDs showed uniform diamond grain distribution and sintered well.Figure 2(a) and (b) show the microscopy photographs of PCDs with relatively fine and coarse grain sizes. The dark parts are diamond grains and the white dotted boundaries are cobalt binders. It is clearly observed that diamond grains are bonded to each other with some cobalt residual existing at the grain boundaries.

Figure 2 Microscopy photographs of PCDs with (a) fine and (b) coarse grain size. (Magnification: × 1000)

It is found that the wear scar area generally increases with the grain size of diamond grits although a linear relation is not strictly followed. In general, a negative correlation is observed between the abrasion resistance of PCDs and the grain size of diamond grits.

Nitrogen content and surface quality of diamond grits

Figure 3shows the average nitrogen contents of three different types of G30 and G22 measured using LECO Nitrogen Analyzer. It is shown that Type A diamond powders have a higher nitrogen content than Type B and Type C. For G30, the nitrogen level of Type B powders is slightly higher than Type C while for G22, the nitrogen content of Type B and Type C are nearly same.

Figure 3 The average nitrogen content of three types of G30 and G22 diamond grits.

Figure 4(a) and (b) show the SEM images of G30 diamond grits (Type A) before and after the compaction at 7 GPa. It is observed that the original, generally uniform coarse diamond grits were smashed into smaller grits with few relatively coarse ones. The original diamond powders have a relatively clear and smooth appearance while after compression, the smashed diamond grits showed sharp edges and rough surfaces. Obviously, the crushing occurred during the high pressure compaction helped the further dense of the diamond bed before the sintering with the infiltration of liquid cobalt.Figure 5(a) clearly displayed the particle distribution shifted after the compaction at 7 GPa.

Figure 4 (a) The photoof original G30diamondgrits(Type A) beforethepress. (b) The photoof the samediamondgrits after compactionat 7 GPa. (Magnification: × 500)

Figure 5 Particle size distribution plots of G30 (a) before and after compaction, (b) after compaction at 7 GPa, (c) after compaction at 8 GPa. (d) Particle size distribution plots of G22 after compaction at 7 GPa.

Figure 5(b) and (c) are the particle distribution plots of G30 diamond grits after the compaction at 7 GPa and 8 GPa, respectively. Figure 5(b) clearly disclosed that the crushing rate of Type A diamond grits is higher than Type B and C. It does indicate that the diamond grits (Type B and C) with lower nitrogen contents exhibited a high compression fracture strength than Type A ones, which is agree with the literature [5]. Brookes and Daniel reported that [5] at room temperature, a reduction in the concentration of single substitutional diamond increases the indentation hardness of the diamond. Figure 5(c) showed that the particle distribution plots of G30 Type A and Type B are nearly same after the compaction at 8 GPa. Type C ones share the same particle distribution as Type A and Type B as well. Just for a clear appearance of the plots, the data of Type C is not included in Figure 5(c). It means that the advantage of higher compression fracture strength of Type B and C diamond powders due to the lower nitrogen content disappeared when the pressure increased from 7 GPa to 8 GPa. Figure 5(d) showed the particle distribution plots of G22 diamond grits after compaction at 7 GPa. The 3 different types of diamond grits shared a very similar particle distribution except Type C showed a marginally lower crushing rate than the other two types. It means that for G22 diamond, type B and C loose the advantage of higher compression fracture strength at lower pressures (say 4-5 GPa but no data available) and hence exhibit a similar grain size distribution at 7 GPa for all three types. Type C powders appeared to have a rougher surface s associated with reduced stress concentration sharp edges after an etching heat treatment, which might explain the slightly lower crushing rate ifFig. 5(d) is accurate. However, how the Type C powders’ surface quality affect the cold compaction, hot compaction and following diamond sintering is not clear yet. Because all three types of G22 diamonds already crushed similarly at 7 GPa, it is reasonable to believe that they would crush similarly at 8 GPa. Therefore no cold compaction test is carried out at 8 GPa.

Figure 6(a) (b) and (c) showed the microstructures of PCDs sintered from the three different types of G30 diamond grits. All PCD microstructures are uniform and look very similar.Figure 6(d) is the percentages of diamond areas extracted from the image analysis. Generally speaking, the three types of PCDs showed a similar diamond area percentage except that Type C one had a slightly lower diamond area.

Figure 6 (a) (b) and (c) Microscopy photographs of PCDs individually sintered from G30 Type A, B and C diamond grits with the magnification of × 1000. (d) The percentages of diamond area in the microstructure of PCDs sintered from G30 diamond grits.

Figure 7(a) (b) and (c) are the microstructure of PCDs sintered from the three different types of G22 diamond grits. They are uniform and look very similar as well.Figure 7(d) showed that the percentages of diamond area of PCDs from Type A and Type B are very similar, both lower than that from Type C.

Figure 7 (a) (b) and (c) Microscopy photographs of PCDs individually sintered from G22 Type A, B and C diamond grits with the magnification of × 1000. (d) The percentages of diamond area in the microstructure of PCDs sintered from G22 diamond grits.

Figure 8(a) and (b) showed the wear scar areas of PCDs sintered from G30 and G22 at 8 GPa, respectively, after the vertical turret test. It turns out that although Type B diamond grits have higher compression fracture strength than Type A due to the lower nitrogen content, the abrasion resistance of PCDs is not necessarily improved. Actually, the abrasion resistance tested in this study decreased for both G22 and G30 as the diamond grits changed from Type A to Type B. The reason is unclear yet. It may rely on the vertical turret test which might be more sensitive to the grain boundary rather than the diamond grit itself. Or it may because less plastic deformation occurred at high temperature in diamond grits with lower nitrogen content, therefore the sintering process is affected accordingly. According to [5], when the temperature is high enough (1400࢑C), an increase in nitrogen content is reflected in a decrease in the volume of plastic deformation associated with impressions. On the other hand, bearing in mind that after HPHT sintering, the total nitrogen level in PCDs changed. At HPHT conditions, nitrogen atoms become mobile in diamond lattice, therefore the original internal nitrogen interstitial can diffuse outside and the external nitrogen could enter diamond as well. However, it seems to suggest that Type C powders might be beneficial for the improvement of abrasion resistance of PCDs whatever the percentage of diamond area is higher or lower. The reason might be related to the increased surface area due to the enhanced roughness of diamond grit and also to the potential more active surface on the diamond grits after the etching process. The further study is needed for the surface quality of diamond grits and how they affect the bonding between diamond to diamond during sintering.

Figure 8 Plots of wear scar areas of PCDs sintered from 3 different types of G30 and G22 diamond grits at 8 GPa.

CONCLUSIONS

Considering the limited data and the complication of PCD cutters’ abrasion performance, it is too early to draw some solid conclusion. However, the main findings from the present study can be summarised as below.

The abrasion resistance of PCDs generally decreases as the grain size increases.

Type B and Type C diamond grits show lower nitrogen content which could help G30 to crush less under 7 GPa but not at under 8 GPa.

For G22, Type B and Type A diamond grits crushed similarly under 7 GPa. Type C diamond grits crushed slightly less than Type B under 7 GPa, which might be attributed to the higher roughness of diamond grit surface.

Although diamond grits of Type B with lower nitrogen contents are harder than Type A ones, it is not necessarily beneficial for the improvement of PCD's abrasion resistance.

Type C diamond grits of both G22 and G30 seem to help improve the abrasion resistance of PCDs, which might be due to the increased surface area of diamond and the potential enhanced activeness during sintering.

REFERENCES

Scott 2006, The history and impact of Synthetic Diamond Cutters and Diamond Enhanced Inserts on the Oil and Gas Industry

Valentine Kanyanta, Hard, super hard and ultrahard materials: An overview, Microstructure-Property Correlations for Hard, Superhard, and Ultrahard Materials, © Springer International Publishing Switzerland 2016, P15

Robert Fries, Patent number 9120204, Polycrystalline superhard material

J. J. Barry, T. P. Mollart, R. W. N. Nilen, patent number 9095918, Cutter structures, inserts comprising same and method for making same

E.J. Brookes, R.D. Daniel, Influence of nitrogen content on the mechanical properties of diamond, Properties, growth and applications of diamond, published by: INSPEC, 2001.
