Immittance Spectroscopy - Mohammad A. Alim - ebook

Immittance Spectroscopy ebook

Mohammad A. Alim

0,0
699,99 zł

Opis

This book emphasizes the use of four complex plane formalisms (impedance, admittance, complex capacitance, and modulus) in a simultaneous fashion. The purpose of employing these complex planes for handling semicircular relaxation using a single set of measured impedance data (ac small-signal electrical data) is highly underscored. The current literature demonstrates the importance of template version of impedance plot whereas this book reflects the advantage of using concurrent four complex plane plots for the same data. This approach allows extraction of a meaningful equivalent circuit model attributing to possible interpretations via potential polarizations and operative mechanisms for the investigated material system. Thus, this book supersedes the limitations of the impedance plot, and intends to serve a broader community of scientific and technical professionals better for their solid and liquid systems. This book addresses the following highlighted contents for the measured data but not limited to the:- (1) Lumped Parameter/Complex Plane Analysis (LP/CPA) in conjunction with the Bode plots; (2) Equivalent circuit model (ECM) derived from the LP/CPA; (3) Underlying Operative Mechanisms along with the possible interpretations; (4) Ideal (Debye) and non-ideal (non-Debye) relaxations; and(5) Data-Handling Criteria (DHC) using Complex Nonlinear Least Squares (CNLS) fitting procedures.

Ebooka przeczytasz w aplikacjach Legimi na:

Androidzie
iOS
czytnikach certyfikowanych
przez Legimi
Windows
10
Windows
Phone

Liczba stron: 633




Guide

Cover

Copyright

Contents

Begin Reading

Pages

ii

iii

iv

v

xiii

xiv

xv

xvi

xvii

xviii

xix

xx

xxi

xxii

xxiii

xxiv

xxv

xxvi

xxvii

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230

231

232

233

234

235

236

237

238

239

240

241

242

243

244

245

246

247

248

249

250

251

252

253

254

255

256

257

258

259

260

261

262

263

264

265

266

267

268

269

270

271

272

273

274

275

276

277

278

279

280

281

282

283

284

285

286

287

288

289

290

291

292

293

294

295

296

297

298

299

300

301

302

303

304

305

306

307

308

309

310

311

312

313

314

315

316

317

318

319

320

321

322

323

324

325

326

327

328

329

330

331

332

333

334

335

336

337

338

339

340

341

342

343

344

345

346

347

348

349

350

351

352

353

354

355

356

357

358

359

360

361

362

363

364

365

366

367

368

369

370

371

372

373

374

375

376

377

378

379

380

381

382

383

384

385

386

387

388

389

390

391

392

393

394

395

Scrivener Publishing100 Cummings Center, Suite 541JBeverly, MA 01915-6106

Publishers at ScrivenerMartin Scrivener ([email protected])Phillip Carmical ([email protected])

Immittance Spectroscopy

Applications to Material Systems







Mohammad A. Alim

Department of Electrical Engineering and Computer Science Alabama A & M University Huntsville, Alabama, U.S.A.









This edition first published 2017 by John Wiley & Sons, Inc., 111 River Street, Hoboken, NJ 07030, USA and ScrivenerPublishing LLC, 100 Cummings Center, Suite 541J, Beverly, MA 01915, USA© 2018 Scrivener Publishing LLCFor more information about Scrivener publications please visit www.scrivenerpublishing.com.

All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, except as permitted by law. Advice on how to obtain permission to reuse material from this title is available at http://www.wiley.com/go/permissions.

Wiley Global Headquarters111 River Street, Hoboken, NJ 07030, USA

For details of our global editorial offices, customer services, and more information about Wiley products visit us at www.wiley.com.

Limit of Liability/Disclaimer of WarrantyWhile the publisher and authors have used their best efforts in preparing this work, they make no representations or warranties with respect to the accuracy or completeness of the contents of this work and specifically disclaim all warranties, including without limitation any implied warranties of merchantability or fitness for a particular purpose. No warranty may be created or extended by sales representatives, written sales materials, or promotional statements for this work. The fact that an organization, website, or product is referred to in this work as a citation and/or potential source of further information does not mean that the publisher and authors endorse the information or services the organization, website, or product may provide or recommendations it may make. This work is sold with the understanding that the publisher is not engaged in rendering professional services. The advice and strategies contained herein may not be suitable for your situation. You should consult with a specialist where appropriate. Neither the publisher nor authors shall be liable for any loss of profit or any other commercial damages, including but not limited to special, incidental, consequential, or other damages. Further, readers should be aware that websites listed in this work may have changed or disappeared between when this work was written and when it is read.

Library of Congress Cataloging-in-Publication Data

ISBN 978-1-119-18485-0

In the name of Allah, the Beneficent, the Merciful

Dedicated to

Father

:

Mohammad Alim Biswas

, M.Sc., Ph.D., D.I.C., (1927 – 2009) son of

Moulavi

Mohammad Bhadu (Bahadur) Biswas (1885 – 1961) and

Mosammat

Saleha Khatun (1894 – 1970), who provided inspiration to comprehend general science beside navigating mathematics, chemistry, physics, history, geography, philosophy, and exposing world religions including exercising english and other global languages;

Mother

:

Mosammat

Jinnatun Khatun

(1934 –), daughter of

Moulavi

Mohammad Boytullah Mondol (1894 – 1976) and

Mosammat

Rowshan Ara Khatun (1904 – 1990), who guided to comprehend Bangla language making literature easy and walking through mathematics;

Wife

:

Sanjida Khanam

, M.Sc., M.S., M.S.M.E., (1957 –), daughter of Muhammad Aminuddin (1919 – 2001) and

Mosammat

Anosha Khatun (1930 – 1989), who helped in achieivng academic and professional goals; and

Four Children

: Nasiha Muna, Sabiha Runa, Maliha Lubna, and Mohammad E. Alim who helped in many ways to materialize this work.

Background of this Book

While the complicated multi-component polycrystalline system was hunting the answer for the underlying operative mechanisms (UOMs), a few questions emerged a few decades ago despite speculated theories bouncing all over reputed journals. At that time impedance spectroscopy began walking. What is the meaning of the term ‘spectroscopy’ for the measured impedance or the admittance or the phasor data? Is it just data acquisition as a function of applied frequency or something else? Is it only the impedance plot that causes the term impedance spectroscopy? Why is there no presence of an admittance plot when the same data are acquired and used though the name admittance spectroscopy is used? In order to answer these questions the materialization of this book emerged to help the understanding of the investigators and the new learners for the generations to come. As of today, the three existing books on the subject demonstrated successfully and efficiently single complex plane (SCP) analysis for the measured data along with elegant theories, relevant or non-relevant, but therein it remained difficult to comprehend the meaning of spectroscopy when it involves impedance or admittance or phasor form of the measured data.

In the most recent decades, a separate assertive parasitic name emerged as the electrochemical impedance spectroscopy (EIS) among the users of the immittance data. What is EIS? In general, impedance spectroscopy is in use for a variety of solid material systems that include electronic or ionic type single crystals and polycrystals, hybrid semiconductors, electrolytes, composites, etc., beside the liquid and biological systems emphasizing reactions in many electrochemical materials. Each material system is not limited to the use of impedance spectroscopy. A widespread frequency range strengthens the horizon of the investigation. Therefore, using an emphasized “word” in front of this term does not increase the horizon or density or intensity or importance of the in-depth investigation.

The generalized form of impedance spectroscopy is already adequate or self-contained for every material system as the fathom depends only on the acquisition of the ac small-signal electrical data. Does one need hybrid impedance spectroscopy as a hybrid system investigator, or quality impedance spectroscopy as a quality control professional? The entire theory and basis of impedance spectroscopy (IS) are the same regardless of the material system. The acronym “IS” is ready to alternate between impedance spectroscopy and immittance spectroscopy though it is used in the first book for impedance spectroscopy in 1987.

The terms impedance spectroscopy and admittance spectroscopy (AS) are explained vividly using relevant situations and cases. The real-world situation is more complicated with respect to the nature of the material systems. For the polycrystalline systems, obtaining two consecutive semicircles in the impedance plane does not mean that grains and grain boundaries are explored. What about the role of the defects and traps having discontinuities in grain-to-grain contacts though ohmic contacts for the electrodes are ignored? Are these defects relaxed or non-relaxed? Are these traps distributed over a range of energy levels? What is the distribution of time constant?

It is amazing that the conceptual term for impedance or admittance of a circuit came to the scientists and engineers shortly after Michael Faraday offered modern electricity to mankind. Nearly a hundred years after Michael Faraday, immittance emerged as a hybrid word originating from impedance and admittance. Though the common sense wisdom serves better, it is known that the impedance plot did not float before the classic Cole-Cole plot in 1941. This breakthrough indicated that the material systems, liquids or solids, require a broader window for investigation to understand the science or engineering aspects of learning. How does the impedance plot become the sole single complex plane (SCP) analytical tool for the entire material systems? How does admittance spectroscopy never use an admittance plot but instead uses some other plot?

Despite the existence of the three separate books on impedance spectroscopy covering both solid and liquid systems, this book is prepared to serve a broad range professionals handling concurrent relaxations in multiple complex planes for the same set of measured ac small-signal electrical data. Through this book the use of multiple complex plane analysis in a simultaneous fashion for the same set of measured electrical data is strongly encouraged, and exercised with demonstrations to surmount every stack of problems. The pedagogical or tutorial contents available today on this subject do not address adequately the use of concurrent multiple complex planes (CMCP) apart from the advantages or disadvantages of apprehending complicated underlying operative mechanisms (UOMs) within the device under test (DUT). The extraction of the meaningful and logical equivalent circuit model possessing interpretation follows from the concurrent multiple complex plane analysis (CMCPA) of the data.

This book is certainly designed to serve the advanced knowledge seekers dealing with benefits of multiple complex plane representations of the data to unravel the UOMs for the DUT. This book encourages to wide-open the window of investigation. It is also designed to serve as a broad range reference on the immittance spectroscopy where complexity of the material system is severe. Thus, this book is directed toward the advanced researchers as well as the learners comprising of graduate and undergraduate students in several disciplines at any global corner. The undergraduate students of all disciplines of engineering, physics, chemistry, and applied sciences can use this book as a reference for the fundamentals of electrical circuits, basics of semiconductor physical electronics, electrical properties of material systems, and characterization of engineering materials besides undertaking senior design and analysis projects in this area of technology.

This book is organized in such a way that there is no duplication or repetition or redundancy as the concept of Concurrent Multiple Complex Plane Formalisms (CMCPFs) is established serving applications and purpose of the DUT. A few problems are incorporated at the end of each chapter to serve practice sessions. It is expected that the learners and the investigators are used to with the computers and spreadsheets beside the access to the available software for data acquisition and necessary analyses. Overall the content provides a worthy source of information for the investigators working in multidisciplinary areas. Background principles, basics of measurements, knowledge on instrumentation, and detailed analysis or analytical procedures are not included in this book because similar content already exists.

The immittance spectroscopy is such a subject that one has to get absorbed or immersed in it with heart and mind possessing strong inspection capability, and subsequent assessment for any set of frequency window possessing number of data points. There is no scope of guessing or speculation for extrapolation of the observed behavior of the DUT. It is a fact that with the level of experience it is possible to visualize the duality of the circuits or duality of the complex planes just seeing or inspecting the feature of one complex plane. Bode plots often mask such tangential behavior. This achievement requires heavy practice and understanding the walking nature of the data points on the semicircle for any DUT. This book has attempted to provide that kind of concept to the interested readers, learners, and investigators.

The CMCPFs apply to all four complex planes in a simultaneous fashion for the same set of measured data. Representation of the measured data in one selected choice of a complex plane via impedance or admittance or capacitance or modulus plot is referred to as the SCP plot besides using a number of favorable and non-favorable Bode plots. This approach somehow paves the initial road for understanding lumped contribution for the DUT. When all four complex planes are used concurrently the road becomes wider. Thus, the effect of using lumped parameter/complex plane analysis (LP/CPA) and Bode plane analysis (BPA) is emphasized together with spectroscopic analysis (SA).

The meaning of the duality of the equivalent circuit models (ECMs) obtained from one or more complex planes in a simultaneous fashion is explained. The complexities of these equivalent circuits originated from a single set of measured data are not averted but dealt with by way of published examples. Converting one form of circuit to another form clearly demonstrates how LP/CPA can influence each complex plane. Nevertheless, two simultaneous circuits obtained from two complex planes allow a more visionary window than a single circuit obtained from a single complex plane via better exposure of the underlying operative phenomena. Among the highlighted topics, concurrent multi-plane analysis and their usefulness of developing equivalent circuit is an important issue, particularly, when no usual semicircular relaxation appears in the template impedance plot or classic Cole-Cole plot.

The first book
